The Avanti JXN-26 is the new standard in refrigerated centrifugation – and with Windows®-based software, a large touchscreen, and network capability, it meets all current requirements for modern device and data management. Remote control and monitoring are possible from any network-connected PC and, optionally, from smartphones via the MobileFuge app. User, device, and data management can be conveniently performed from the office.
The Avanti JXN-26, with its maximum speed of 26,000 rpm, centrifuges tubes from 1.5 ml up to a volume of 6 x 1 liter.
The centrifuge offers centrifugal forces of up to 82,000 x g and is compatible with existing J-rotors.
In addition to centrifuging all common tubes and bottles, it can also centrifuge microtiter plates, filtration kits, and DNA kits.
The Avanti JXN-26 operates with the innovative FRS (Friction Reduction System) and SR (Switched Reluctance) drive, achieving significantly better energy efficiency than comparable centrifuges in this class. The centrifuge features a two-stage rotor safety system for clear rotor safety identification.
Technical Specifications:
Maximum Speed: 26,000 rpm
Maximum g-force: 81,770 xg
BioSafe: Yes
Acceleration: Maximum or time-controlled (1–10 minutes from 0–500 rpm)
Deceleration: Maximum, time-controlled (1–10 minutes from 500–0 rpm) or idle
Time-controlled operation: 99 min. 59 sec. continuous operation, intermittent operation
Maximum Capacity: 1–6 l
Cooling System: CFC-free, ozone-preserving refrigerant
Drive Type: Cooling: SR Drive* / Air-cooled
Temperature Range: -10°C to +40°C in 1°C increments
Rotor ID: Automatic
Zone Capability: Yes
Pollution Degree: 2
Installation Category: II
Material: Plastic, steel, structural foam
Finish: Powder coating
Weight: 290 kg
Width: 71 cm
Depth: 86 cm
Height: 86 cm
Clearances: 7.6 cm (sides) and 16 cm (rear)
Humidity: 80% (non-condensing)
Power supply: 200–240 V AC, 50/60 Hz
Condition: Used, technically and visually very good
